Compact Optics Round for COB
Silicone optics for COB modules with a LES of up to 23 mm
The highly temperature-resistant and self-sealing silicone optics offer optimum protection against the ingress of dirt, dust and water with a protection rating of up to IP65. The family offers light distributions that can be used in both road and industrial applications. The optics are compatible with the latest COBs and thus guarantee sufficient power density in applications with very high light requirements. The high heat and UV resistance ensures long-term functionality.
Product benefits
- High temperature resistance
- Protection class (incl. gasket) IP65
- Self-sealing capability
- Suitable for luminaires with impact resistance IK08/5.0
- UV-resistance
- Wide beam angle: 120°
- Optical efficiency: up to 97%
Choose a variant:
Compact Optics Round for COB Silicone 100 mm dia. IP65
| Ref. No. | Type | Light distribution | Light distribution | Family data sheet | Material | Light transmission | Surface texture | Diameter | Height | LED technology |
|---|---|---|---|---|---|---|---|---|---|---|
| 562512 | COB lens Area |
|
Area | silicone | clear | high-glossy | 100 | 23mm | COB | |
| 562513 | COB lens SYM II |
|
SYM II | silicone | clear | high-glossy | 100 | 24.6mm | COB | |
| 559042 | COB lens Mclass |
|
ASYM | silicone | clear | high-glossy | 100 | 24mm | COB |
| Ref. No. | Type | Light distribution |
|---|---|---|
| 562512 | COB lens Area | Area |
| 562513 | COB lens SYM II | SYM II |
| 559042 | COB lens Mclass | ASYM |
| Ref. No. | Type | Light distribution | 2D data | 3D data |
|---|---|---|---|---|
| 562512 | COB lens Area |
|
||
| 562513 | COB lens SYM II |
|
||
| 559042 | COB lens Mclass |
|
| Ref. No. | Type | Light distribution | ldt und ies data |
|---|---|---|---|
| 562512 | COB lens Area |
|
|
| 562513 | COB lens SYM II |
|
|
| 559042 | COB lens Mclass |
|
| Ref. No. | Type | Light distribution |
|---|---|---|
| 562512 | COB lens Area |
|
| 562513 | COB lens SYM II |
|
| 559042 | COB lens Mclass |
|
| Ref. No. | Type | ||
|---|---|---|---|
| 562512 | COB lens Area | ||
| 562513 | COB lens SYM II | ||
| 559042 | COB lens Mclass |
| Ref. No. | Type | 2D data | 3D data |
|---|---|---|---|
| 562512 | COB lens Area |
|
|
| 562513 | COB lens SYM II |
|
|
| 559042 | COB lens Mclass |
|
